BM100/BM200 Metal Seated Ball Valves | ||||||||||||||||||||||||||||||||||||
BM100 and BM120 series are metal seated
ball valves, which adopt High Velocity Oxygen Fuel (HVOF) to coat tungsten
carbide or chromium carbide on metal ball surface and valve seat sealing
surface. Thermal spraying process is adopted for nickel base alloy spraying on
ball surface and stellite-alloy surfacing on valve seat sealing surface.
Hardness strengthening is done on the supporting sealing surface. Special
high-speed grinding machine, spherical turning lathe, grinding and turning ball
and valve seat is applied to ensure spherical degree of the ball. Finally
special rubbing machine and process of SCORE is adopted to perform supporting rubbing
of ball and valve seat in order to ensure complete sealing of the sealing pair.
Zero-leakage can be achieved under best situation.
Ball and valve after supporting rubbing
will completely attached to form seamless sealing surface which may prevent
impurities from entering in an effective way. When the ball is rotating, the
valve seat sealing surface may scrap impurities attached on the ball surface to
realize self-cleaning function.
Specifications
| ||||||||||||||||||||||||||||||||||||
